The Adamson Metrix is an ultra compact 2-way true line source array enclosure which provides unmatched clarity for speech reinforcement and medium SPL for smaller to mid-size venue installations, or for use as an underhang-, side-, front- or balcony fill enclosure in larger installations. The Metrix offers lightning fast rigging and multiple uses for applications of all sizes. The Metrix line is available with AIR™ laser cut steel touring rigging, or with EIR™ installation rigging (-i) with reduced weight and costType a description for this product here...
| Frequency Range (+/-3 dB) | 95Hz - 18kHz |
| Nominal Directivity (-6 dB) H x V | 120° x 5° |
| Maximum Peak SPL** | 136.5 |
| Components LF | ND8-LM 8" Kevlar Neodymium Driver |
| Components HF | B&C DE800 3" Diaphragm / 1.4" Exit Compression Driver |
| Nominal Impedance LF | 16 Ω |
| Nominal Impedance HF | 16 Ω |
| Power Handling (AES / Peak) LF | 250 / 1000 W |
| Power Handling (AES / Peak) HF | 110 / 440 W |
| Rigging |
The AIR™ Revolving Disc System consists of laser cut steel precisely cut to accommodate 6 positions of splay. The EIR™ Plate System is a reduced cost and weight solution ideal for permanent installations. |
| Connection | 2x Speakon™ NL8 |
| Height Front (mm / in) | 217 / 8.56 |
| Width (mm / in) | 540 / 21.25 |
| Depth (mm / in) | 420 / 16.5 |
| Weight (kg / lbs) | 24.2 / 53.5 (-t), 19.7 / 43.5 (-i) |
| Supported Processing | Lake, XTA |
