The LD Systems Roadbuddy 10 is an elegant solution for voice and music transmission on the go. The 2-way speaker with a 10" custom woofer and a 1" compression driver is operated with a rechargeable battery for up to 8 hours and is powered by a class D power amplifier with a highly efficient switching power supply and 480 watts of peak power.
The Roadbuddy relies fully on wireless transmission: it has an UHF radio receiver which operates in the license-free 863 - 865 MHz range, and can be expanded with an additional system. The on-board Bluetooth player with backlit multifunction display ,equalizer, USB port and SD card slot supports the mp3, wma and wav formats. A handheld microphone with 10 mW output power(LDRBUD10) or as an alternative a headset microphone with belt pack (LDRBUD10HS) and an IR-remote control for the player are included.
For wired devices, the Roadbuddy has two channels with combo jacks and individual volume controllers that are switchable for microphone and line level, a stereo input via RCA (Cinch) sockets (mono summed) and a 3.5 mm Aux input. Treble, Bass, Echo and Master volume controllers complete the control panel.
The LD Systems Roadbuddy is easily transportable thanks to built-in castor wheels and a pull-out handle. On the top, there is a handy storage compartment for up to two hand-held transmitter microphones. The plastic housing of this lightweight device has been designed to accommodate a 35 mm tripod mount.
| Product number: | LDRBUD10HS |
|---|---|
| Product type: | Battery-powered PA speaker |
| Low/mid driver dimensions: | 10" |
| Woofer size: | 254mm |
| Woofer magnet: | Ferrite |
| Woofer brand: | Custom-made |
| HF driver dimensions: | 1" |
| HF driver dimensions (mm): | 25.4mm |
| HF driver magnet: | Ferrite |
| HF driver brand: | Custom-made |
| Amplifier: | Class D |
| RMS: | 120W |
| Peak power: | 480W |
| Frequency response: | 55 - 18000Hz |
| SPL (1W/1m): | 96dB |
| Max. SPL: | 115dB |
| Protection circuits: | short circuit, overload protection, over-current |
| Controls: | Master Volume, Echo, CD / Tape IN Level, high, low, AUX / MP3 switch, Mic 2 Level, Mic 1 Level |
| Indicators: | Power, Charge/battery status |
| Media player | |
| Supported media: | SD Card, USB stick, Bluetooth |
| Supported formats: | WMA file, WAV-CD, MP3 file |
| Media player controls: | Play / Pause, Mode (Menu / Bluetooth /SD / USB), Next Track, Repeat, Stop, Previous Track, equalizer |
| Media player display elements: | Lighted multifunctional LC display |
| Line inputs: | 1 |
| Line input connectors: | 2 x RCA, 6.3 mm jack, 2 x XLR, 3.5 mm jack |
| Mic inputs: | 2, 2 x XLR, 6.3 mm jack |
| Wireless Unit | |
| Transmission frequency range: | 863 - 865MHz |
| Modulation Type: | FM |
| Channels: | 16 |
| Frequency Response Wireless Unit: | 50 - 17000lx @ 1mHz |
| Controllers Wireless Unit: | ASC, Mute Level (Squelch), Value Up, Value Down, Power / Volume |
| Indicators Wireless Unit: | LED Display, AF (LED), RF (LED) |
| Connections Wireless Unit: | nTNC for receiver antenna |
| RF Transmitter Power Output: | 10mW |
| Bodypack weight: | 0.08kg |
| Bodypack material: | ABS plastic |
| Operating voltage: | Switching power supply, 220 V - 240 V AC / 50 Hz, 100 V - 120 V / 60 Hz |
| Rechargeable batteries: | 12 V / 5 Ah |
| Cabinet material: | polypropylene |
| Cabinet construction: | vented |
| Width: | 415mm |
| Height: | 525mm |
| Depth: | 328mm |
| Weight: | 16.5kg |
| Other features: | extendable handle, IR Remote for Media Player, Stand mount 36 mm, transport handle, Transport casters |
