Allen & Heath SQ-5 Digital Mixer 48ch, 96kHz

$5,999.99 $4,589.99
You save: $1,410.00
Current stock: 0
Description

Description

Allen & Heath SQ-5 Digital Mixer  48ch, 96kHz

48-channel Digital Mixer, with 17 Faders, 6 Fader Layers, 32 x 32 USB Interface, and Network Audio Support. Based on Allen & Heath's acclaimed XCVI 96kHz FPGA audio engine, the SQ-5 digital mixer delivers extensive live sound mixing capabilities

Next-generation Digital Mixing   Based on Allen & Heath's acclaimed XCVI 96kHz FPGA audio engine, the SQ-5 digital mixer delivers extensive live sound mixing capabilities. Even with its powerful processing, the SQ-5 delivers best-in-class audio quality with less than 0.7ms of latency. You'll have a lot of flexibility when it comes to creating monitor mixes, with up to 12 stereo mixes (groups or auxes) in addition to the main LR out. Eight stereo FX engines provide studio-quality effects, with dedicated returns. Complete with a 32 x 32 USB audio interface, and dedicated controls for mixing convenience, the Allen & Heath SQ-5 is a smart mixing solution for live music, worship sound, and educational facilities.

Capable mixer that's ready to expand   Right out of the box, the SQ-5 digital mixer offers 48 input channels. You have 17 faders for hands-on mixing, arranged in six fader layers for managing larger mixes. The SQ-5 also offers an SLink port for remote audio and expansion. And a 64-channel I/O port is ready for network audio integration.

Manage large mixes easily with Automatic Mic Mixing   When you're mixing a multi-mic setup, you'll find the SQ-5's Automatic Mic Mixing capabilities to be a huge help. It's also a fantastic "safety net" when relying on inexperienced volunteers to manage the sound system. With Automatic Mic Mixing, you can be sure that you'll never experience an excessive imbalance between mic levels in large multi-mic applications.

Built-in audio interface and comprehensive I/O   Multitrack recording is made simple with the Allen & Heath SQ-5, with its built-in 32 x 32 USB audio interface. Engineers at Sweetwater also appreciate the convenience of direct recording to a USB drive. A 64-channel I/O port is also present for connecting to network audio. And an SLink port allows for remote audio and I/O expansion.

Allen & Heath SQ-5 Digital Mixer Features:  48-input digital mixer with 96kHz FPGA processing  Best-in-class audio quality, with less than 0.7ms latency  17 faders for hands-on mixing, with 6 fader layers  Create up to 12 stereo mixes in addition to the main LR mix  3 stereo matrices  8 stereo FX engines with dedicated effects returns  7" capacitive touchscreen for navigation  SLink port for remote audio and I/O expansion  64-channel I/O port for network audio  Built-in 32 x 32 USB audio interface for multitrack recording  SQ-Drive allows for direct recording to a USB drive  Dedicated physical controls, plus 8 assignable SoftKeys  Automatic Mic Mixing makes it easy to manage large multi-mic setups  AES digital output  Rackmountable

Tech Specs  Type:  Digital  Channels:  48  Inputs - Mic Preamps:  16 x XLR  Phantom Power:  16 channels, Talkback  Talkback:  1 x XLR  Inputs - Line:  16 x XLR (mic/line)  Inputs - Other:  2 x 1/4" (ST1), 2 x 1/4" (ST2), 1 x 1/8" (ST3)  Outputs - Main:  2 x 1/4" (A out, B out), 2 x XLR (L,R)  Outputs - Digital:  1 x XLR (AES)  Outputs - Other:  12 x XLR (stereo mixes, L/R)  MIDI I/O:  USB (control)  Remote:  1 x 1/4" (footswitch)  Data I/O:  1 x EtherCon (dSnake, DX mode, gigaACE), 1 x Ethernet RJ-45 (LAN TCP/IP)  USB:  1 x Type B, 1 x Type A  Computer Connectivity:  USB (32 x 32), Ethernet  Inserts:  Internal Pre EQ/Compressor  Busses/Groups:  36 bus  I/O Expansion Slots:  1 x Option card port (Dante, Waves)  Headphones:  1 x 1/4"  A/D Resolution:  24-bit/96kHz  Faders:  17 x 100mm motorized  EQ Bands:  Parametric EQ, 28-band Graphic  Effects:  Delay, Reverb, Chorus, Flanger, Phaser (8 x RackFX engine)  Signal Processing:  Dynamics  DAW Control:  MIDI DAW control via USB  Screen:  7" color touch screen  Storage:  USB Type A (16 x 16)  Software:  Wireless Remote Mixing app iPad/Android (network router not included)  Rackmountable:  Yes (kit sold separately)  Power Source:  AC Adapter  Height:   7.8"  Depth:   20.3"  Width:   17.3"  Weight:   23.1 lbs.  Manufacturer Part Number:  AH-SQ-5

Powered by Allen & Heath’s revolutionary XCVI 96kHz FPGA engine, SQ-5 is built for professionals in the most demanding live sound applications. Delivering class-leading high resolution audio with an ultra-low <0.7ms latency, the SQ-5 gives you unrivalled power and audio fidelity. The mixer has 16 onboard preamps and 8 stereo FX engines with dedicated return channels and access to the acclaimed RackExtra FX library. 12 stereo mixes (configurable as groups or auxes) make SQ the perfect companion for in-ear monitoring setups, whilst Automatic Mic Mixing* takes the strain in multi-mic environments. SQ-5 gives you all the tools to meet any requirement, from AV and corporate events to live productions and houses of worship.

96kHz XCVI Core

SQ is a future-proofed, next-generation console, powered by Allen & Heath’s 96kHz XCVI FPGA engine. XCVI delivers class-leading high resolution audio quality, ultra-low latency of <0.7ms, variable bit depth for ultimate precision and noise performance, mix coherency down to the sample, and the sheer power to handle high channel / mix counts and ample FX / processing. .

DEEP processing ready

SQ’s DEEP processing architecture allows owners to hand-pick boutique compressor and preamp emulations to suit their style and needs. DEEP plugins can be embedded directly within the mixer’s inputs and mix channels, all without adding system latency or setup hassles.

The Ultimate IEM Mixer

With no less than 12 stereo mixes, super-low latency, and both parametric and graphic EQ on every mix, SQ is the perfect companion for in-ear monitoring setups. SQ’s airline-friendly compactness and rugged build quality mean there’s no reason to gamble on house monitor consoles again.

Expandable up to 48 mics

SQ-5 has all the onboard I/O you need for standalone operation. Thanks to its SLink intelligent port, SQ can also be expanded up to a total of 48 mic inputs via a family of 96kHz and 48kHz rack and stage box expanders (e.g. AB168, AR2412, AR84 and DX168), making it a flexible, mix ‘n’ match solution for owners of other Allen & Heath digital systems. You can also link your SQ directly to another SQ or even a dLive system.

Dante, Waves and more

SQ is the centrepiece of a growing ecosystem of apps, expanders, audio networking, personal mixers and more, allowing you to connect, adapt and expand to your heart’s content. It’s compatible with leading audio networking standards too – add an audio networking card such as Dante or Waves to SQ’s I/O port and you’re ready to integrate with installed systems, provide a digital FoH / Monitor split and more.

Flexible multitrack recording

The integrated SQ-Drive makes it quick and easy to capture a 96kHz multitrack or stereo recording of the show direct to a USB key or drive. No software setup, no soundcard driver issues and no extra laptop to bring to the performance. SQ-Drive is also a smart way to manage walk-in music.

Also provided is a built-in 32×32 96kHz audio interface for multitrack recording, backing tracks or virtual soundcheck applications. The interface is Core Audio and ASIO compliant and comes complete with MIDI and DAW control capabilities.

 Advanced AMM*

SQ’s advanced automatic mic mixer (AMM) features make it a natural choice for mixing conferences, panel talks and TV shows. It’s fully integrated in the mixer too, with no extra latency, so you don’t need to route the audio to an internal DSP rack or an external plugin system.

Designed for the pro

We know that the live environment can be tough on gear – that’s why we devised our most punishing regime of testing and retesting yet for SQ. From its 3-tier, all metal chassis to its extruded aluminium light bar, SQ has tremendous strength and rigidity underlying its good looks.

The Mixing Experience

With each new design, the Allen & Heath team strives to get closer to the ultimate mixing experience. SQ’s dashboard is centred around a high-res 7” capacitive touchscreen, framed by an array of high-grip, illuminating encoders to create an intuitive, integrated blend of clear visual feedback and immediate, hands-on control. Channels and mixes can be dragged and dropped to any strip, with custom naming and colour coding on the colour strip displays, allowing you to build a mixing environment that mirrors your own workflow. Each strip features our patented Chromatic channel metering system, giving you at-a-glance level indication thanks to LEDs with variable brightness and colour.

RackExtra FX

Allen & Heath has a well-earned reputation for crafting FX emulations that rival the very best plug-ins, but with none of the associated hassle. SQ is armed with 8 stereo FX engines and features the acclaimed RackExtra library of emulations of legendary classic reverbs, gated reverbs, delays, modulators and more. All FX have dedicated stereo returns so you don’t need to waste input channels.

ME Personal Mixing System

SQ is fully compatible with the ME Personal Mixing System, allowing the performers to take control of their own monitor mixes. Any number of ME-1 and ME-500 personal mixers can be daisy-chained from the mixer’s SLink port, or from a connected remote expander . 48 Input Channels DEEP Processing ready 17 Faders / 6 Layers 12 Stereo mixes + LR 3 Stereo Matrix 8 Stereo FX Engines + dedicated returns 7” capacitive touchscreen SLink port for remote audio / expansion 64ch I/O Port for audio networking .. 32×32 USB audio interface SQ-Drive direct recording to USB AES output Chromatic channel metering Integrated LED illumination Dedicated physical controls 8 Assignable SoftKeys Channel LCD displays 19” rack mountable

Part Number:  AH-SQ-5
